Connect Cashfree

Cashfree offers full Indian method coverage — UPI, Cards, Net Banking, Wallets, Pay Later, EMI and PayPal — with a choice of redirect or popup checkout. Connect it on the Addons → RelyPay → Providers page.

Addons → RelyPay → Providers → Cashfree

Credentials you will need

On the Cashfree card, fill in these fields exactly:

Field	Where to find it
App ID	From Cashfree Dashboard → Developers → API Keys
Secret Key	From Cashfree Dashboard → Developers → API Keys

Both values come from the same Developers → API Keys screen in the Cashfree Dashboard.

Options

• Test Mode — toggle. Enable for sandbox testing. Turn this on to point RelyPay at Cashfree's sandbox while you trial the integration, and turn it off for live payments.
• Checkout Mode — choose Redirect (Full Page) or Popup (Modal). How the checkout is displayed. Redirect sends the customer to a full Cashfree page; Popup keeps them on your site in a modal.

Register the webhook

1. On the Cashfree card in RelyPay, copy the webhook URL shown.
2. In the Cashfree Dashboard, add that URL as your webhook/notification endpoint.
3. Subscribe to these events:

Event	Required?
PAYMENT_SUCCESS_WEBHOOK	Required
PAYMENT_FAILED_WEBHOOK	Required
PAYMENT_USER_DROPPED_WEBHOOK	Optional

SSL required

The webhook URL must be HTTPS. Cashfree will not deliver events to an insecure endpoint, and RelyPay verifies each callback's signature.

Sandbox testing

With Test Mode enabled, use your Cashfree sandbox App ID and Secret Key to place trial payments without moving real money. When you are satisfied, switch to your production keys and disable Test Mode.

Test it

1. Click Test Connection on the Cashfree card to confirm your keys reach Cashfree.
2. Enable Cashfree and save.
3. Place a test payment through a RelyPay sub-gateway that Cashfree can serve, and confirm the result appears in the transaction log with Cashfree as the provider.
